Paragon 2-Piece Front Rotors Pair – Toyota GR Supra Mk5 3.0 / BMW Z4 G29 / M Sport G-Series – 348 x 36mm

Upgrade your Toyota GR Supra Mk5 3.0 or BMW Z4 G29 with Paragon’s 348 x 36mm 2-piece front rotors for track-ready braking performance, improved cooling, and weight savings. These rotors are a direct bolt-on solution, retaining full OEM compatibility while offering enhanced consistency and durability under aggressive driving.

Why Choose Paragon Rotors?

• Built for spirited driving and track days
• Reduces unsprung weight while increasing thermal efficiency
• Floating 2-piece design controls heat-induced distortion
• CBN machining for true, vibration-free braking surfaces

Key Features

• 348 x 36mm rotor size with directional ventilation vanes
• Up to 30% cooler operation than OEM discs under heavy braking
• Slotted rotor face improves bite and disperses gas and water
• Fully-floating 2-piece design with D-Bobbin (Long), 10-bolt configuration
• CM-250 high-carbon alloy rotor rings with heat treatment for durability
• CBN-machined for smooth pad contact and improved pad bedding
• Each rotor weighs 11.3 kg (24.9 lbs), approx. 1.8 kg (3.9 lbs) lighter than OEM

Construction

Rotor Rings

Made from Paragon’s CM-250 high-carbon cast iron, the rotor rings are heat-treated to prevent internal stress and cracking under load. CBN precision machining ensures a flat surface for consistent braking and reduced vibration.

Aluminium Hats

The rotor hats are CNC-machined from aerospace-grade 6061-T6 aluminium and hard anodised to MIL-A-8625 Type III spec for maximum durability. Material is strategically removed to reduce weight while maintaining strength under high loads.

Finish Options

• Clear Hard Anodised: Will not discolour under track heat – best for motorsport use
• Black Dyed Hardcoat: May discolour above 260°C – suited for street/mixed use

Compatibility

• Toyota GR Supra Mk5 3.0 – Front
• BMW Z4 G29 M Sport – Front
• BMW G-Series M Sport – Front

Fitment Notes

• Direct bolt-on installation – no modifications required
• Maintains OEM ABS, brake bias, and system compatibility
• Compatible with OEM and aftermarket pads of identical pad depth (D)

Technical Specifications
