Fuel Cells and Accessories
Fuel Cells and Accessories
This collection covers Radium Engineering fuel cells and the hardware that completes them: fillers and caps, roll over valves, dry break fittings, sender plates, gaskets, replacement cans and bladders, and mounting kits. These parts sit within our Fuel System range and suit competition builds where the factory tank is replaced or upgraded. Most items are universal, so the right choice depends on your cell's size, bolt pattern and port sizes rather than your car.
Shop by Product Type
- Fuel cells, including the Radium Engineering RA-Series Fuel Cell (FIA-FT3 Certified)
- Replacement fuel cell cans (including a 22 gallon option) and replacement bladders for RA-Series cells
- Remote mount fillers, swing valve filler caps and FCST filler adapters (6-bolt to 3-bolt)
- Roll over valves, Dynamic Safety Valves (DSV), DSV extension adapters and fuel cell vent kits
- Dry break fittings, including a 1.5" male PRV and a 1" probe restrictor
- Fuel level senders, sender gaskets, 5-bolt SAE block-off plates and fuel level gauge mounts
- Fuel cell gaskets, weld flanges and nut rings
- Dry carbon fibre fuel cell lids
- Mounting hardware: weld-in cages, mounting tab kits, spare tyre well mounting kits and saddle tank conversion kits
- Fuel vent charcoal canister service kits and fuel tank pressure plugs
To complete the system, see fuel pumps, fuel surge tanks, fuel pump hangers, fuel line kits, fuel filters, fuel pressure regulators, refuelling equipment and fuel system accessories. You can browse every brand we carry on our brands page.
Choosing the Right Part
Match accessories to your cell, not your car. Before ordering, confirm these details:
- Cell capacity: Some parts are size-specific, such as the 10/14 gallon carbon fibre lid and the 22 gallon replacement can.
- Plate bolt pattern and size: Examples include the 24-bolt / 6x10in fuel cell gasket, 5-bolt sender plates and gaskets, and 6-bolt to 3-bolt FCST filler adapters.
- Port thread and outlet size: Roll over valves come in 12AN ORB to 8AN male and 10AN ORB to 19mm barb versions, and the DSV is 12AN ORB to 12AN male.
- Cell depth: Deep cells may need the FCST lift pump extension (203mm add-on).
- Vehicle-specific items: A small number of parts are made for one car, such as the fuel tank pressure plug for the Mitsubishi Lancer Evolution X (CZ4A).
If you compete, check your category's regulations for fuel cell, venting and roll over valve requirements before you buy.
Installation & What You'll Need
Installation by a professional is recommended. Follow the manufacturer's instructions for sealing plates and gaskets, and tighten fasteners evenly in a cross pattern so the plate doesn't distort.
Plan for the following:
- AN spanners
- A fuel-rated thread sealant where tapered threads are used
- Fresh O-rings or crush washers on reassembly
Pressure test anything that carries fuel before the car is used. Race fuel cells and their plumbing are generally intended for competition vehicles, so check your build against state road rules before fitting anything to a registered car.
FAQ
Will these accessories fit any brand of fuel cell?
Not automatically. Bolt patterns and port sizes vary between manufacturers, so check the bolt circle, plate size and thread size on your cell before ordering.
Are these parts compatible with E85 or methanol?
Fuel compatibility varies by product. Check the individual listing or ask our team before ordering.
Do I need a roll over valve?
Roll over protection is an important part of a vented fuel cell. Check your category's regulations for the specific requirements.
Do you ship Australia-wide?
Yes, we ship to every state and territory, including regional addresses.
