Tomei Ti RACING Titanium Muffler - Nissan 200SX / Silvia (S14) - SR20DET
Ti RACING is Tomei's top titanium exhaust, now redesigned for the SR20DET Nissan 200SX / Silvia (S14). It runs an 80.5 mm main pipe, one of the largest on the market for this car, into a large straight-through main silencer and a 120 mm sub-silencer. The whole system weighs 6.3 kg against about 16.0 kg for the factory exhaust.
Tomei built Ti RACING for circuit work: it keeps the flow of a straight-through race exhaust but packs in more long-strand glass wool than the EXPREME Ti, to bring the noise down for track-day sound limits. The new layout sits higher than the previous model, about 2 mm more clearance beside the diff and 18 mm more at the main silencer, and the longer burnt-titanium tip is shaped to suit the rear bumper. A bolt-in sound reducer is included for quieter running when you need it.
Note: Competition use only. This product is not intended for use on registered road vehicles – check your state's noise and emissions requirements before use on the road. This S14 muffler, with its longer tip, is also Tomei's pick for an S15 wearing a deep aftermarket rear bumper; for a standard S15 see the Tomei Ti RACING Titanium Muffler - Nissan 200SX / Silvia (S15) - SR20DET. Installation by a professional is recommended.
Features
- Tomei's own titanium, refined and formed in-house
- 80.5 mm main pipe, 1.0 mm wall
- 152 mm straight-through main silencer and 120 mm sub-silencer
- 115 mm straight-cut burnt titanium tip with laser-engraved Tomei logo
- Mirror-finish silencer shell with stamped Tomei logo
- 6.3 kg, against about 16.0 kg for the factory exhaust
- Removable sound reducer included
Pairs Well With
- Tomei Full Cast Turbo Outlet Pipe - Nissan Silvia / 180SX / 200SX (PS13/RPS13/S14/S15) - SR20DET
- GFB Hybrid Dual Port Blow Off Valve - Nissan 200SX (S14/S15)
- ARP Head Stud Kit - Nissan SR20DET - Silvia / 180SX / 200SX (S13 / S14 / S15)
- HARDRACE Engine and Transmission Mounts - Nissan Silvia / 180SX / 200SX (S13/S14/S15) - Race Version
Shop more: Tomei for Nissan Silvia, 180SX & 200SX · Tomei
Need help choosing parts? Contact our team at sales@chicaneaustralia.com.au.
Product
- Brand
- Tomei
- Series
- Ti RACING
- Part number
- 441016
Details
- Engine
- SR20DET
- Material
- Titanium
- Main pipe diameter
- Φ80.5 mm
- Pipe thickness
- 1.0 mm
- Main silencer diameter
- Φ152 mm
- Sub-silencer diameter
- Φ120 mm
- Exit diameter
- Φ115 mm, straight cut
- Flange thickness
- 8.0 mm
- Flange inner diameter
- Φ80.5 mm
- Sound level (Tomei test)
- 81.0 dB idle / 103.2 dB at 4,500 rpm
- Weight
- 6.3 kg (factory approx. 16.0 kg)
- Use
- Competition / off-road only
Contents
- 1 x Main pipe A
- 1 x Main pipe B
- 1 x Silencer assembly
- 1 x Sound reducer
- 1 x Gasket
- 2 x Clamp bands
- 4 x Springs
- 1 x Silencer band
- 1 x Silencer band rubber
- 2 x M10 flange nuts
- 1 x M8 flange nut
- 1 x M8 flange bolt
- 1 x M6 button bolt
- 1 x Allen key
No instructions available for this product.
