Radium Fuel Pump Hanger Nissan GT-R (R35)

Radium Fuel Pump Hanger – Nissan GT-R (R35) – 10AN/8AN ORB, 1–3 Pump

Radium Engineering builds fuel system components to motorsport-grade tolerances, and this fuel pump hanger is no exception. Machined from billet aluminium and engineered as a true drop-in replacement, it gives Nissan GT-R (R35) owners a serious platform for high-power fuel system builds — without any permanent modifications to the vehicle.

This listing covers the Radium Engineering Fuel Pump Hanger, SKU 20-0572, designed specifically for the R35 GT-R. The hanger supports one, two, or three aftermarket fuel pumps in brushed or brushless configuration, with port sizing of 10AN ORB female (outlet) and 8AN ORB female (return). The installer supplies their own pumps and completes final assembly.

Important: Walbro DCSS 39/50 E85 pumps (F90000267, F90000274, F90000285, F90000295) are not physically compatible with this hanger. Brushless pump installations require a separate standalone controller. A third brushed pump will require custom wiring specific to the pump model and trigger strategy used. Venturi jet pumps consume 15–45 LPH depending on fuel pressure — factor this into pump sizing. If fuel pressure must hold after engine shutdown, check valves must be installed in the feed line.

Key Features

• Drop-in OEM replacement — no cutting, drilling, or permanent modifications required
• Supports 1, 2, or 3 fuel pumps (brushed or brushless) in any combination
• Anodised aluminium collector box with integrated fuel starvation protection
• Three integrated 355 LPH one-way fill valves (1,065 LPH total fill capacity)
• Reconfigured venturi jet pump plumbing preserves OEM saddle-tank transfer function without restricting the regulator return
• 10AN ORB female outlet port / 8AN ORB female return port
• 6-hole fuel return diverter
• High-current stainless steel electrical studs — hermetically sealed, ETFE-insulated wiring
• Non-conductive anodised aluminium acorn nuts prevent accidental short circuits
• Reuses OEM temperature and fuel level sensors
• Sock filters included for all three pump inlets
• Compatible with 39mm diameter pumps including AEM 50-1200 and Walbro GSS342 (255 LPH)
• Compatible with up to three Ti Automotive E5LM brushless fuel pumps; check valves supplied to prevent back-flow
• Stainless steel hardware throughout
• OEM hard line compatible
• Compatible with petrol, E85, ethanol, methanol, and flex fuel applications
• CNC machined billet aluminium construction

Vehicle compatibility, OEM part numbers, and fitment notes are provided in the tabs above. Please confirm your vehicle's year, trim level, and configuration before ordering.

Not sure if this hanger suits your build? Contact our team at sales@chicaneaustralia.com.au for expert advice.
