Radium Engineering Top Feed Conversion Fuel Rails
Not sure which option fits your application? Contact Us - we're happy to help.
Radium Engineering Top Feed Conversion Fuel Rails - Subaru WRX / STI (EJ20 V1-V2)
These Radium Engineering conversion fuel rails bolt onto the OEM side-feed intake manifold of early Subaru EJ engines, including the Subaru Impreza WRX / STI (GC, V1-V2), and convert it to modern top-feed injectors (SKU 20-0579-02). That opens up a wide choice of high-flow injectors for performance builds with no permanent modification.
Each rail has three 8AN ORB ports (six in total) for flexible plumbing, and press-fit spacers insulate the rails from intake manifold heat. The rails are CNC machined from 6061 aluminium, black anodised and compatible with all fuels including E85.
Note: Suits top-feed injectors with 14mm upper and lower O-rings and 34mm height, such as Injector Dynamics ID1050, ID1300, ID1700 and ID2600 XDS-34-14-14. Do not use WRX-fitment injectors. Injectors and fittings are sold separately. Installation by a professional is recommended.
Features
- Converts OEM side-feed manifolds to top-feed injectors
- 3 x 8AN ORB ports per rail (6 total)
- Billet injector seats for 14mm lower O-rings
- Press-fit thermal insulating spacers
- CNC-machined 6061 aluminium, black anodised
- Direct bolt-on, no permanent modification
- E85 compatible
Pairs Well With
- Radium Engineering Fuel Rail Plumbing Kit (Parallel) - Subaru WRX / STI (EJ20 / EJ25)
- Radium Engineering Fuel Rail Plumbing Kit (Series) - Subaru WRX / STI (EJ20 / EJ25)
- Radium Engineering Fuel Pump Hanger - Subaru WRX / STI (GC / GD)
- Radium Engineering Intake Manifold Gasket - Subaru WRX / STI (EJ20 / EJ25)
- Radium Engineering MPR Multi-Port Regulator - Universal
Need help confirming fitment? Contact our team at sales@chicaneaustralia.com.au.
Product
- Brand
- Radium Engineering
- Type
- Top feed conversion (side feed manifold)
- Part number(s)
- 20-0579-02
Details
- Ports
- 3 x 8AN ORB per rail (6 total)
- Injector compatibility
- Top feed, 34mm height, 14mm upper and lower O-rings
- Material
- CNC-machined 6061 aluminium, black anodised
- Thermal insulation
- Press-fit spacers
- Fuel compatibility
- All fuels including E85
- Injectors
- Not included
Contents
Black anodised, laser-etched aluminium fuel rails (x2)
Black anodised EJ V1–2 fuel rail mounting brackets (x2)
Black anodised, laser-etched 26mm injector seats (x4)
Thermal insulating press-in spacers (x4)
Stainless steel M8x1.25 mounting bolts (x4)
Vehicle fitment
Universal fit: this part suits any car. Check the specifications above for sizes and fittings.
| Make | Model | Chassis | Years | Versions | Engine | Brakes | Position |
|---|
Can’t see your car? Ask us and we’ll check fitment for you.
