AWE Touring Edition Exhaust Toyota GR Corolla (GZEA14)

AWE Touring Edition Exhaust – Toyota GR Corolla (GZEA14)

The AWE Touring Edition is a downpipe-back exhaust for the Toyota GR Corolla. It has a 76mm (3") mid-pipe inlet and a stamped stainless merge that splits into three 64mm (2.5") outlets. AWE's 180 Technology® resonator cuts out the specific frequencies the 1.6L three-cylinder sends into the cabin at highway speed. Straight-through bullet resonators at the rear keep the tone aggressive without rasp. AWE notes both editions are aggressive; the Touring just removes the highway drone. AWE measured up to 2.2 kW (3 hp) and 1 Nm (1 ft-lb) at the wheels.

Video

Sound clip – Touring and Track Edition on a Toyota GR Corolla

Choose Chrome Silver or Diamond Black. Either way you get a 114 x 203mm (4.5" x 8") oval double-walled slash-cut centre tip flanked by two 127mm (5") double-walled slash-cut tips. The finish is the only difference between the two part numbers.

Note: The 76mm (3") inlet also suits aftermarket downpipes with a 76mm (3") connection. It is non-valved; an integrated mount relocates the factory valve motor securely. A Touring-to-Track Conversion Kit is available if you later want it louder. Installation by a professional is recommended.

Features

• Touring Edition: 180 Technology resonator for no highway drone
• Single 76mm (3") to triple 64mm (2.5") design with stamped merge
• Straight-through bullet resonators at the rear
• Mandrel-bent T304L stainless, 1.65mm (0.065") wall
• 21.1 kg (46.5 lb) with clamps and tips
• 114 x 203mm oval centre tip and two 127mm (5") tips, double-walled
• Integrated valve motor mount
• Up to 2.2 kW (3 hp) at the wheels (AWE dyno figures)
• Direct bolt-on

Need help confirming fitment? Contact our team at sales@chicaneaustralia.com.au.
