APR Stage 3 PowerMax GT2563S Turbocharger System - Volkswagen Golf R (MK8)
APR has built a reputation for pushing the EA888 platform further than most tuners dare, backing every stage with months of calibration testing rather than guesswork. The APR Stage 3 PowerMax GT2563S Turbocharger System (SKU T4100010) is their flagship bolt-on upgrade for the Volkswagen Golf R, built around a Garrett GT2563S turbocharger and APR's Stage 3 software.
This listing covers the Volkswagen Golf R (Mk8, CD) fitted with the 2.0T EA888.4 engine. The kit is a direct bolt-on replacement for the factory Continental turbocharger and is designed to run on just an upgraded intake and intercooler, with no exhaust, fuelling, or sensor changes required at this power level.
Key Features
- Garrett GT2563S turbocharger, direct bolt-on to factory location
- 20% increase in compressor flow, 37% increase in turbine flow over factory turbo
- Mar-M alloy turbine wheel rated to 1050°C
- APR Stage 3 software upgrade included
- High and low torque software configurations available
- Installation kit included
Vehicle compatibility, part numbers, and fitment notes are provided in the tabs above. Please confirm your Golf R's model year and configuration before ordering.
Not sure if this kit suits your build? Contact our team at sales@chicaneaustralia.com.au for expert advice.
Vehicle Compatibility
| Make | Model | Chassis | Engine |
|---|---|---|---|
| Volkswagen | Golf R | Mk8 (CD) | EA888.4 |
Technical Specifications
| Spec | Value |
|---|---|
| Turbocharger Model | Garrett PowerMax GT2563S |
| Engine Compatibility | MQB/MQB Evo 2.0T EA888.4 (280-333 PS) |
| Power Output | 478-543 HP (357-405 kW), depending on octane level |
| Torque Output | 409-435 ft-lbs (555-590 Nm), depending on octane level |
| Compressor Flow Increase | 20% over factory Continental turbocharger |
| Turbine Flow Increase | 37% over factory Continental turbocharger |
| Turbine Wheel Material | Mar-M alloy, rated to 1050°C |
| Software | APR Stage 3 calibration, available in high and low torque configurations |
| Required Supporting Mods | Intake and intercooler only |
