Turbosmart TS-2 5862 Supercore - B-Frame Water Cooled
The Turbosmart TS-2 5862 supercore is the rotating assembly of the TS-2 5862 B-Frame turbocharger (58mm compressor inducer, 62mm turbine exducer), supplied without a turbine housing. Use it to rebuild an existing TS-2 5862 or to build a turbo around the Turbosmart turbine housing of your choice.
Note: A Turbosmart B-Frame turbine housing to suit the 62mm turbine wheel is required and is sold separately. Choose reverse rotation only for a reverse rotation (mirror) turbo setup. TS-2 supercores are water cooled as well as oil cooled. Installation by a professional is recommended.
Need help choosing a supercore? Contact our team at sales@chicaneaustralia.com.au.
Vehicle Compatibility
| Make | Model | Chassis | Engine |
|---|---|---|---|
| Universal | TS-2 5862 B-Frame turbochargers | - | - |
Technical Specifications
| Spec | Value |
|---|---|
| Brand | Turbosmart |
| Series | TS-2 (oil and water cooled) |
| Frame | B-Frame |
| Compressor inducer | 58mm |
| Turbine exducer | 62mm |
| Turbine housing | Not included |
| Bearing system | Proprietary dual ceramic bearing system |
| Rotation | Standard or reverse |
| Part numbers | TS-29-SC2W-5862 (Standard), TS-29-SC2W-5862-RR (Reverse) |
