Radium Engineering Fuel Pump Hanger Chevrolet Corvette (C5/C6) Pumps Not Included

Radium Engineering Fuel Pump Hanger - Chevrolet Corvette (C5/C6) - Pumps Not Included

The Radium Engineering fuel pump hanger replaces the factory unit in the mid 2003-2013 Chevrolet Corvette and is set up to run one aftermarket fuel pump of your choice (SKU 20-0980). An integrated collector is kept full by crossover fuel scavenged from the passive side of the tank, low-pressure fuel returning from the regulator, and two one-way fill valves, keeping the pump fed during aggressive driving.

Electrical connections use custom stainless steel studs that are hermetically sealed, serviceable and handle high current better than compact multi-pin connectors. Non-conductive anodised aluminium acorn nuts guard against accidental shorts, and the in-tank wiring is insulated with chemically resistant ETFE. Choose your pump based on engine power target, fuel type and fuel pressure.

Note: Fuel pumps are not included. A fuel pressure regulator and a low-micron external fuel filter must be purchased separately (the Radium Corvette plumbing kits include both). Running two pumps requires the separate dual pump add-on (20-0937). Single pump installs can reuse the OEM pump wiring, although an upgrade is recommended so the pump receives full power. For 41-43mm OD pumps, the 20-0441 pump clamp is required. Designed around the US-market vehicle; please confirm fitment on Australian-delivered vehicles with our team before ordering. Installation by a professional is recommended.

Features

• Configured for 1 aftermarket fuel pump (2 with the 20-0937 add-on)
• Pump outlet: 10AN ORB female (7/8"-14) with 8AN male adapter supplied
• Return inlet: 8AN ORB female (3/4"-16) with 6AN male adapter supplied
• Integrated collector with two one-way fill valves, 355LPH each
• Hermetically sealed stainless steel electrical studs
• ETFE insulated in-tank wiring

Need help confirming fitment? Contact our team at sales@chicaneaustralia.com.au.
