Overview
NGK Racing Series spark plugs are built to handle the extreme conditions of high-performance and motorsport engines. Featuring a fine-wire iridium-tipped centre electrode and platinum-tipped ground electrode, these plugs deliver superior ignitability, enhanced throttle response, and exceptional durability under pressure.
With a heat range of 8, these colder spark plugs are ideal for high-boost turbocharged engines and competition use. A pure alumina silicate ceramic insulator ensures optimal heat transfer, while a copper core and triple-sealed design guarantee consistent performance and leak-free reliability. Corrugated ribs prevent flashover, making them perfect for high-RPM or high-compression applications.
Key Features
- Fine-wire iridium centre electrode for long-lasting performance and efficient ignition
- Platinum-tipped ground electrode for enhanced durability under high heat
- Heat range 8 – suited for high-boost, high-RPM engines
- Corrugated ribs prevent flashover during high voltage operation
- Triple-sealed for maximum leak prevention
- Pure alumina silicate insulator for superior strength and heat transfer
- Copper core for excellent thermal conductivity and consistent spark
Technical Specifications
| Specification | Details |
|---|---|
| Thread Diameter | 14 mm |
| Thread Pitch | 1.25 mm |
| Seat Type | Gasket |
| Reach | 26.5 mm (1.04") |
| Hex Size | 5/8" (16 mm) |
| Terminal Type | Solid |
| Gap | 0.028" (0.7 mm) |
| Centre Electrode | Iridium, 1.0 mm Fine Wire |
| Projection | Non-Projected |
| Ground Electrode | Platinum, Slant Type |
| Heat Range | 8 (Colder – Suitable for high-performance applications) |
| Resistor | Yes – 5k Ohm |
| Torque Spec | Cast Iron: 18–25.3 lb. ft. / Aluminium: 18–21.6 lb. ft. |
What's Included
- 5 × NGK Racing Series Spark Plugs
