ARP Head Stud Kit – Audi DAZA 2.5T FSI (12pt ARP2000)

Overview

The ARP Head Stud Kit (Part No. 204-4708) is a critical upgrade for Audi 2.5T TFSI DAZA and DNWA engines found in the RS3 and TT RS. Designed to deliver reliable and consistent clamping force under high-boost and high-temperature conditions, this kit eliminates the common issues associated with OEM torque-to-yield bolts.

Manufactured from ARP2000 material and precisely engineered for the EA855 EVO engine block, these studs provide superior head gasket sealing and allow for multiple re-torques, making them ideal for performance street builds and motorsport applications alike.

Key Features

Includes 12 high-strength ARP2000 head studs
Precision-machined washers with anti-spin stamped face
ARP 12-point nuts for uniform torque loading
Re-usable – unlike factory TTY bolts
Maintains head gasket seal under high boost and detonation
Includes ARP Ultra-Torque fastener assembly lubricant

Installation Notes

Clean and dry all cylinder head and washer seating surfaces prior to assembly
Studs are installed hand-tight only – do not torque them into the block
Use ARP Ultra-Torque Lubricant on threads and under nut heads
Washer stamped side faces down toward cylinder head
Follow factory torque sequence in three stages:

Stage 1: 25 ft-lbs
Stage 2: 50 ft-lbs
Stage 3: 70 ft-lbs

What's Included

12 × ARP2000 Head Studs
12 × Hardened Washers (stamped side down)
12 × 12-point ARP Nuts
1 × Packet of ARP Ultra-Torque Fastener Assembly Lubricant
ARP Installation Instructions

Vehicle Compatibility

Audi RS3 (8V / 8Y) – 2.5 TFSI DAZA / DNWA
Audi TT RS (8S) – 2.5 TFSI DAZA
Fits EA855 EVO engines with factory 12-stud cylinder head configuration
