Injector Dynamics Fuel Injectors - Toyota GR Yaris (GXPA16) / GR Corolla (GZEA14) / Lexus LBX Morizo RR - G16E-GTS Set of 3
Upgrade the fuel system on your G16E-GTS-powered Toyota or Lexus with Injector Dynamics fuel injectors, built to spec in partnership with Bosch Motorsport and engineered specifically for the motorsport tuner. Injector Dynamics injectors are the established benchmark for accurate, repeatable fuelling at high pressure and across all known fuels, with industry-leading flow data and characterisation supplied for every set.
This listing covers the Toyota GR Yaris (GXPA16), Toyota GR Corolla (GZEA14) and Lexus LBX Morizo RR (GAYA16) — all powered by the 1.6L G16E-GTS turbocharged three-cylinder engine. Each kit is supplied as a matched set of three injectors with the correct top and bottom o-rings, plugs and pins for a direct plug-and-play fitment to the factory fuel rail and harness.
Multiple flow rates are available, ranging from supporting bolt-on builds through to high-power E85 and methanol applications. Use the product options on this page to select the injector best suited to your fuelling target and tune.
Available Flow Rates
- ID1050x — 1065cc/min nominal flow. Ideal for stock-turbo and mid-power E85 builds.
- ID1300x² — 1340cc/min nominal flow. All-stainless internals, designed for alternative fuels.
- ID1750x — 1750cc/min nominal flow. High-output E85, methanol and big-turbo applications.
- ID2600-XDS — 2600cc/min nominal flow. Dedicated motorsport applications and extreme-output builds.
Key Features
- Built-to-spec motorsport injector developed in partnership with Bosch Motorsport
- Corrosion-resistant internals compatible with petrol, ethanol, methanol, E85 and race fuels
- Compact body designed to fit short-body fuel rail applications including the G16E-GTS
- Stable operation up to 10 bar fuel pressure (1050x and 1750x)
- Replaceable inlet filter for extended service life
- USCAR / EV6 electrical connector — direct plug-in to factory harness
- Comprehensive injector characterisation data supplied with every set
Kit Contents
- 3 x Injector Dynamics injectors (matched set)
- Top and bottom o-rings (pre-fitted)
- USCAR adaptor plugs and pins
- Injector characterisation data sheet
Vehicle compatibility, OEM fitment notes and injector specifications are provided in the tabs above. Please ensure your vehicle's engine code and fuel system are confirmed before ordering.
Not sure which injector size is right for your build? Contact our team at sales@chicaneaustralia.com.au for expert advice.
No instructions available for this product.
Injector Dynamics
How to Measure an Injector
Injector sizing isn’t just about flow rate — physical dimensions matter too. Each Injector Dynamics part number includes length and O-ring sizing so you can ensure a proper fit.
Take the example 60.11.14:
- Overall length in mm (from O-ring to O-ring) = 60.1mm
- Top O-ring diameter (in mm) = 11mm
- Bottom O-ring diameter (in mm) = 14mm
What makes Injector Dynamics better than other aftermarket injectors?
Injector Dynamics is the only injector supplier to provide full dynamic flow data and latency values across voltage and pressure ranges. This data is essential for precise ECU tuning — something generic injectors simply can’t offer.
Yes. Every set is flow-matched not just statically, but dynamically — meaning flow characteristics are tested under real-world operating conditions. This ensures even fuel delivery across all cylinders and better performance.
Proper injector characterisation allows tuners to precisely control fuelling across all load conditions. This means better idle, drivability, fuel economy, and peak performance — especially with modern ECUs that rely heavily on accurate fuel modelling.
Most ID injectors are available in multiple body lengths, connector types, and O-ring configurations to ensure direct fitment for a wide range of vehicles. No modifications are needed when the correct spec is chosen.
Yes. All ID injectors are compatible with ethanol-based fuels, including E85. They’re built using corrosion-resistant internals and tested extensively with aggressive fuels to guarantee reliability and performance.
Injector Dynamics is trusted by professional race teams, top tuners, and OEM-level motorsport programs around the world. From time attack builds to 1000+hp street cars, they’re the go-to choice when reliability and data accuracy matter.
Every ID injector set includes full documentation, tuning data, and connector details. This makes it easier for your tuner to dial in your setup without guesswork or trial-and-error tuning.
