CP Carrillo PRO-H Connecting Rods – Audi DAZA/DNWA 2.5T FSI (23mm Pin)

Overview

The Carrillo PRO-H Connecting Rod Set (Part No. SCR13678) is engineered for the Audi 2.5 TFSI DAZA/DNWA engine, as found in the RS3 and TTRS. Built for high-boost, high-RPM applications, these forged steel rods offer exceptional strength and reliability under extreme conditions. Designed with a straight I-beam profile, they feature 3/8" bolts and 23 mm pin bore, perfectly matched to aftermarket or upgraded forged pistons with 144 mm centre-to-centre rod length.

Each rod is fully machined, balanced, and ready to handle aggressive performance builds where factory rods are a known weak point. These are trusted globally in drag, time attack, and circuit builds pushing serious horsepower.

Key Features

• Designed for 2.5 TFSI DAZA / DNWA engines with 144 mm C-C length
• PRO-H beam design for maximum strength under tensile load
• High-precision machining and consistent balancing
• Forged steel construction ideal for boost and high RPM
• 3/8" fasteners with Carrillo's WMC6 bolt set
• Suitable for 23 mm piston pins as used in most forged pistons

Technical Specifications

What's Included

• 5 × Carrillo PRO-H Connecting Rods (SCR13678)
• 5 × 3/8" Carrillo WMC6 Rod Bolts

Vehicle Compatibility

• Audi RS3 (8V / 8Y) – 2.5 TFSI DAZA / DNWA
• Audi TTRS (8S) – 2.5 TFSI DAZA
• Compatible with other 2.5 TFSI applications using 144 mm rods and 23 mm pin
